SLIM DESIGN | SOLID POWER

Product Features

Half-Bridge circuit, eliminating high reverse voltage and ensuring high reliability.
Capable of consistently and stably outputting 10% of Max. power
Integrated with multiple safety protection measures
Waterproof, oil-proof and dust-proof PCB design
Supports various communication protocols including UART / RS485 / RS232 / MODBUS RTU

Voltage	Model	Max. Power	Min Power	Coil Inductance
220V~50Hz	HB22AP35	3500W	350W	67~77μH
	HB22AP50	5000W	500W	65~75μH
	HB22AP60	6000W	600W	190~210μH
	HB22AP80	8000W	800W	205~215μH
380V~50Hz	HB38AP35	3500W	350W	67~77μH
	HB38AP50	5000W	500W	190~210μH
	HB38AP60	6000W	600W	190~210μH
	HB38AP80	8000W	800W	205~215μH
