Product Features

Mainboard compatible with half-bridge or single switch technology
Capable of consistently and stably outputting 10% of Max. power
Integrated with multiple safety protection measures
Waterproof, oil-proof and dust-proof PCB design
The partition blocks the mainboard from contacting the outside, providing a strong waterproof effect

Component

Circuit	Voltage	Model	Max. Power	Min Power	Standby Power	Coil to Pot	Coil Inductance
Half Bridge	220V	LRIH-MC28	2800W	300W	≤1.5W	7~9mm	85~95μH
	220V	LRIH-MC35	3500W	300W	≤1.5W	7~9mm	67~77μH
	220V	LRIH-MC50L	4700W	300W	≤2W	12~18mm	65~75μH
	380V	LRIH-3PMC50	5000W	1000W	≤2W	8~14mm	190~210μH
	380V	LRIH-3PMC60	6000W	1000W	≤2W	8~14mm	190~210μH
Single Switch	220V	C28	3000W	1600W	≤2.5W	11~12mm	70~75μH
	220V	C35	3500W	2100W	≤2.5W	11~12mm	70~75μH
	220V	C45	4500W	2700W	≤2.5W	11~12mm	65~70μH
	220V	C50	5000W	3300W	≤2.5W	11~12mm	65~70μH
	220V	C60	6000W	3800W	≤5W	11~12mm	55~58μH
