MORE INSIDE | LESS OUTSIDE

Product Features

Half-Bridge circuit, eliminating high reverse voltage and ensuring high reliability
Capable of consistently and stably outputting 10% of Max. power
Integrated with multiple safety protection measures
Waterproof, oil-proof and dust-proof PCB design
Supports various communication protocols including UART / RS485 / RS232 / MODBUS RTU

Voltage	Model	Max. Power	Min Power	Coil Inductance
220V~ 50Hz	HB22AL35	3500W	350W	70~75μH
	HB22AL50	5000W	500W	60~65μH
	HB22AL60	6000W	600W	60~65μH
380V~ 50Hz	HB38AL50	5000W	500W	190~210μH
	HB38AL60	6000W	600W	190~210μH
	HB38AL80	8000W	800W	205~215μH
	HB38SL10K	10000W	1000W	180~190μH
	HB38SL12K	12000W	1000W	180~190μH
	HB38SL13K	13000W	1000W	180~190μH
