Product Features

Single-Switch circuit, the design is inexpensive and reduces overall manufacturing costs
It features a straightforward architecture, making implementation easier
Integrated with multiple safety protection measures
The technology is well-established and widely used in applications
Supports various communication protocols including UART

Voltage	Model	Max. Power	Min Power	Standby Power	Coil to Pot	Coil Inductance
220V	C28	3000W	1600W	≤2.5W	11~12mm	70~75μH
	C35	3500W	2100W	≤2.5W	11~12mm	70~75μH
	C45	4500W	2700W	≤2.5W	11~12mm	65~70μH
	C50	5000W	3300W	≤2.5W	11~12mm	65~70μH
	C60	6000W	3800W	≤5W	11~12mm	55~58μH
